Type 7 U Boat

[Len Morris 2Participant @lenmorris2]

Hi everybody, I'm trying to find a set of line drawings for a Type 7 hull. There are many illustrations that show plan and elevation but so far I can't find one that shows datumed cross- sections. Can anybody help?. Best Regards, Len

[Len Morris 2Participant @lenmorris2]

[Paul TParticipant @pault84577]

Hi Len

Lots of plans on http://www.uboatarchive.net/U-570GeneralPlan.htm

Paul

[Len Morris 2Participant @lenmorris2]

Hi Paul,

Thank you and apologies for saying thank you so late in the day. Not only did you help me but it looks like in the interim, you helped another 125 people. Are model boat ponds around the UK about to be invaded by Type 7's by this time next year.

Len.

[ashley needhamParticipant @ashleyneedham69188]

Len. I am afraid Bushy park is well served by corvettes, aircraft carriers, subs and a Sunderland which would easily fend off any envisaged U-boat invasion.

Ashley



Edited By ashley needham on 18/07/2014 20:08:12

[Len Morris 2Participant @lenmorris2]

Hi Ashley, that's a really nice picture of two aircraft carriers sailing in tandem. Looks even better through mi periscope. We are also in the picture but you just can't see us cumin!

Len

[ashley needhamParticipant @ashleyneedham69188]

Ha! You wish !!! Ashley (overhead aerial recconaissance pictured as backup)

[Len Morris 2Participant @lenmorris2]

Nice one Ashley. Made me smile! I retire from this thread. (but we are there)!
